Android 9.0 industrial rugged handheld pda for inventory barcode checking
3.2'' IPS Touch Screen+Corning Gorilla Imager Window+13MP/5MP Camera+NFC Optional
Android 9.0 industrial rugged handheld pda for inventory barcode checking
3.2'' IPS Touch Screen+Corning Gorilla Imager Window+13MP/5MP Camera+NFC Optional
Rugged Handheld Terminal:
Powerful Application Performance:Android 9.0, 1G+16G, Micro SD/TF card slot, 64 bit Quad-core with superior data processing capability to run multiple tasks simultaneously, smooth operation.
Built to Last:3.2 inch IPS 480*800 PX with Multi-point touch capacitive screen, Support multi-touch, support wet hand and glove operation, with IP65 water and dustproof capability.
Diverse transmission functions: Support 4G/3G/ Wi-Fi/ Bluetooth, signal stability which does not easily lose connectivity.
You can use the SDK we provide to customize your software
Specification
|
CPU |
ARM Cortex-A53 64-bit Quad-core processor 2.0GHz |
|
Operation System |
Android 9.0 |
|
Memory |
1GB RAM + 16GB ROM (Optional 2+16, 3+32, 4+64) |
|
Expansion Slot |
PSAM x 2; TF x 1; Micro SIM x 2; POGO Pin x 1; Type -C x 1 |
|
Display |
3.2 inch IPS display with 480×800 resolution |
|
Touch Panel |
Support multi-touch, support wet hand and glove operation |
|
Camera |
Rear: 13MP, front: 5MP, auto focus with LED fill light |
|
Imager Window |
Corning Gorilla |
|
Keyboard |
30 keys in total, front keys 26, side keys 4 |
|
Battery |
4.35V 5200 mAh Lithium polymer battery |
|
Power Adaptor |
The Word Standard:input 100-240V;output DC5V 2A |
|
Audio Frequency |
Built-in microphone |
|
Prompt |
Vibration Tip/LED Tip/Audio Tip |
|
Vibration Motor |
Built-in programmable vibration motor |
|
Size & Weight |
182.49mm x 65.56mm x 25.59 mm, 320g (including battery) |
|
WWAN |
2G: GSM (850/900/1800/1900MHz) |
|
WLAN |
Wi-Fi 802.11a/b/g/n |
|
WPAN |
Bluetooth 4.0 (transmission distance: 5~10 meters ) |
|
GPS |
Support GPS/AGPS,BDS |
|
1D Scanning |
Optical resolution ≥ 4 mil, scanning depth of field 3.81 cm - 60.98 cm, scanning angle 47°± 3°(standard), scanning speed 102 times ± 12 times per second (compatible with mainstream brands) 1D: UPC/EAN/JAN, GS1 DataBar, Code 39, Code 128, Code 32, Code 93, Codabar/NW7, Interleaved 2 of 5,Code 2 of 5, Matrix 2 of 5, MSI, Telepen, Trioptic, China Post, etc. |
|
2D Scanning |
Optical resolution ≥ 3 mil, optical resolution omnidirectional, scanning speed 300 times/s 1D: Can read 1D barcodes; 2D: PDF417, MicroPDF417, GS1 Composite, Aztec Code, Data Matrix, QR Code, Micro QR Code, MaxiCode, Hanxin code, etc. |
|
RFID |
NFC: support 13.56 MHz; support ISO14443A/14443B/15693 protocol, reading distance: 2~5cm |
|
|
UHF: support 840-960MHz UHF RFID, reading distance: 2 meters Supports reading and writing of EPC C1/G2, 18000-6C protocol cards and tags |
|
Standard Accessories |
Battery, power adapter, USB cable, hand strap |
|
Charging Interface |
1 Type-C interface |
|
Optional Accessory |
Charging cradle |
|
Development Tool |
Android Studio+Eclipse |
|
Programming Language |
Java |
|
Operating Temperature |
-25℃ ~ 55℃ |
|
Storage Temperature |
-40℃ ~ 70℃ |
|
Humidity |
5% ~ 95% (non-condensation) |
|
Drop spec |
Multiple 1.2m drops to tile over concrete |
|
Sealing |
IP65 |
