Bluetooth Face Recognition Health Code Scanner With Temperature Measurement HS-620
HS-620 can detect 5 moving persons at 4 meters within 0.7 seconds, mainly be designed for turnstile system, EM lock, wall mounted and desktop version.
Features
Specification
|
CPU |
4 cores, 1.8GHz |
|
Memory |
2GB RAM, 8GB ROM |
|
Operating System |
Android 7 |
|
Dimension |
8 inches touch screen, full view angle, IPS LCD screen, resolution 1280*800 |
|
Dual Camera |
2.0M(RGB Camera); 1.3M(InfraredCamera) |
|
Wide dynamic camera
|
Wide Dynamic: Automatic |
|
White Balance: Automatic |
|
|
Aperture: 4m, Focal Length: 0-2m |
|
|
Accessories |
|
|
Card Reader UID(Optional) |
ID/NFC (UID) at optional |
|
Filling Light |
LEDfilling light |
|
QR Code
|
UK Health Code, Safe Entry, Lithuanian Health Code, American Health Code, Canadian Health Code, UAE Health Code, EU Health Code |
|
Interface |
|
|
Network Module |
WIFI (2.4G), Bluetooth, 4G(optional) |
|
Serialport |
RS232, relay |
|
Relay Output |
NC, COM&NO |
|
Wiegand Interface |
Support Wiegand 26 / 34 input / output |
|
Reset Interface |
Yes |
|
RJ45 |
Yes |
|
Face Detection |
|
|
Capacity |
20000 Capacity, Support detecting and tracking 5 people at the same time |
|
Face Recognition |
99.99%, 1:N |
|
Recognize Distance |
Support(0.5-4meters) |
|
Remote Upgrade of Equipment |
Support |
|
Stranger Detection |
Support |
|
Fingerprint Scanner |
|
|
Sensor |
FAP10 Capacitive Sensor, 20000 Fingerprint Capacity |
|
FAR |
0.0001% |
|
Image Resolution |
508DPI |
|
Fingerprint Verification Time |
1s |
|
Image Size |
256*360pixel |
|
FRR |
0.01% |
|
General Parameters |
|
|
Certification |
IP64, CE,ROHS |
|
Installation Method |
Turnstile, Wall mounted, Desktop, Floor Type |
|
Power Supply |
DC12V (±10%) |
|
Operating Temperature |
-10° C ~ 60° |
|
Working Humidity |
10% to 90% |
|
Device Size |
310(L)*133(W)*25(H)mm |
|
Weight |
2.5KG (Device Only) |
