UHF Long Range Portable Two Way Radio
Product Description：
·As Juston's flagship product, Q608 is a walkie talkie with high power and high-capacity battery, business appearance and rich functions.
·High-power and high-gain antenna; Q608 two way radio has strong penetrability; can successive penetrate buildings; metal obstacles; ensure clear reception and transmission without distortion.
·16 Preset channels;non-standard CTCSS and DCS can minimize unnecessary chats from other channels.
·Rugged and durable body; dust-proof and drop-proof design; can withstand shock and vibration in harsh environments plus 2-meter drop.
·2800 mAh battery;fully charged can support about 18-21 hours of battery life; meet the needs of standard shifts; low battery alarm reminds you to charge it in time.
·Optional:waterproof shoulder microphone; can provide stable and reliable audio in bad weather; help work crews connect; coordinate and collaborate to get the job done right.
Main Functions
1.VOX
2.SOS
3.Scan
4.1750Hz
5.Scrambler
6.Compandor
7.Battery Save
8.Tail Elimination
9.Battery Report
10.High/ Low Power
11.PC Programmable
12.Wide/Narrow Band
13.SK Programmable
14.Chinese/English Voice Report
15.CTCSS/DCS Support Non-standard
Technical Specification
|
GENERAL |
|
| Frequency Range |
UHF:400-470MHz VHF:136-174MHz |
| RF Output Power | H:10W±1W L:5W±0.5W |
| Channels | 16 |
| Channel Spacing | Wide:25KHz Narrow:12.5KHz |
| CTCSS/DCS | 50 CTCSS / 105 DCS |
| Antenna Impedence | 50Ω |
| Operating Temperature | -20℃+50℃ |
| Operating Voltage | DC 7.4V |
| Battery Type | 2800mAh |
| Dimension(Excluding antenna) | 132(H)×61(W)×43(D)mm |
| Weight(Battery,Antenna Including) | About 280g |
|
TRANSMITTER |
|
| Output Power |
H:10W±1W L:5W±0.5W |
| Modulation | F3E |
| Modulation Sensitivity | 12±5 mV |
| Adjacent Channel Power |
≤-65 dB(Wide) ≤-55 dB(Narrow) |
| Modulation Distortion | ≤5% |
| Transmit Spurious Emission | ≤-65 dB |
| RECEIVER | |
| Reference Sensitivity | ≤-122 dBm |
| Adjacent Channel Selectivity | ≥65 dB |
| Inter-modulation | -55 dB |
| S/N |
≥50 dB (Wide) ≤-40 dB (Narrow) |
| Rated Output Power | ≤1W |
| Rated Audio Distortion | ≤5% |
Packing&Delivery
Two-way Radio Walkie Talkie Gift Box, 10 pcs / carton.
* 1 x HYDX Q608
* 1 x Antenna
* 1 x Battery
* 1 x Charger
* 1 x Belt Clip
* 1 x Hand Strap
* 1 x User Manual
