Our newly product has feature of green low power consumption and rich application scenarios, besides, it is equipped with ergonomic design and very stable, precise, convenient, practical, and efficient.
Specification
|
Performance parameter |
|
|
Image Sensor |
CMOS |
|
Pixel |
640*480 CMOS |
|
illumination |
White light led |
|
Reading code system |
2D:PDF417,QR Code,Data Matrix |
|
1D:Code128,EAN-8,EAN-13,UPC-E,UPC-A,Interleaved 2 of 5, Matrix 2 of 5,Industrial 25,Code 39, Codabar, Code 93, Code 11,MSI-Plessey,GS1-DataBar |
|
|
Reading accuracy |
≥5mil |
|
Bar code sensitivity |
Tilt:±65°@ 0°Roll and 0° Skew |
|
Rotate:±360°@ 0°Pitch and 0° Skew |
|
|
Deflection:±60°@ 0°Roll and 0° Pitch |
|
|
Data interface |
Usb hid-kbw interface, usb virtual serial port, usb hid-pos interface, rs-232 interface |
|
Field of view |
28° horizontal and 21.5° vertical |
|
Typical reading depth of field |
Code 39 5mil 6-8cm 15mil 4-15cm |
|
Physical parameter |
|
|
Size (length * width * height) |
41.2*24*49.2mm (Figure1 ) |
|
weight |
72g (including USB cable) |
|
Prompt mode |
Buzzer, led indicator |
|
Electrical parameters |
|
|
Voltage |
Operating 5VDC±5% |
|
Current |
Working current 210mA Stand-by current 70mA |
|
Environmental parameters |
|
|
Operating temperature |
-20℃~+50℃ (-4°F~122°F) |
|
storage temperature |
-40℃~+70℃ (-40°F~176°F) |
|
Relative humidity |
5%~95% (no condensation) |
|
Accessories list |
|
|
Data line |
USB cable (2m) Usb hid-kbw interface, usb virtual serial port, usb hid-pos interface |
