Waterproof Dustproof Ant-iron filings
Standby 400 hours
Waterproof Dustproof Ant-iron filings
Standby 400 hours
Waterproof
Dustproof
Anti-iron Filings
Standby 400 hours
| General | |
| Frequency Range | UHF |
| Channel Capacity | 16 Channels |
| Channel Step | 25KHz(Wide Band), 12.5KHz(Narrow Band) |
| Frequency Stability | ±2.5ppm |
| Operating Voltage | 7.4V DC ± 20% |
| Operating Temperature | -20℃ ~ +60 ℃ |
| Antenna Impedance | 50Ω |
| Dimension | 136*60*36mm |
| Weight | 260g |
| Transmitter | |
| Output Power | 5W |
| Modulation Mode | 16K0F3E |
| Adjacent Channel Power | ≥65dB |
| Singal Noise Ratio | ≤-40dB |
| Parasitic Harmonic | ≤65dB |
| Spurious Emission | ≤-36dBm |
| Audio Response | 300Hz-3KHz |
| Audio Distortion | ≤5% |
| Receiver | |
| Sensitivity | -120dBm (20db SINAD) |
| Intermodulation | ≥60dB |
| Adjacent Channel Selectivity | ≥60dB |
| Spurious Rejection | ≥60dB |
| Audio Response | 300Hz-3KHz |
| Signal to Noise Ratio | ≥45dB |
| Audio Distortion | ≤5% |
| Audio Output Power | 1W |
